Stainless steel ball valve
Série 231/MM, female thread / welding, NS-norm, reduced bore, DN 10-50, PN 40
DN 10-50
Materials
| Tělo | DN 10-50: Stainless steel, AISI316L (1.4404) |
| Koule | DN 10-50: Stainless steel, AISI316L (1.4404) |
| Těsnění koule | DN 10-50: PTFE+C |
| Vřeteno | DN 10-50: Stainless steel, AISI316L (1.4404) |
| Těsnění vřetena | DN 10-50: FPM/NBR |
Připojení
| female thread / welding, NS-norm |
Ovládání
| DN 10-50 | composite handle |
Provozní podmínky
| Teplota | -20 °C - +200 °C |
| Třída těsnosti | A (EN 12266-1) |
Below -20 °C contact manufacturer. Lowest allowed ambient temperature -40 °C.
DN 10-50
Oblast vody
Oblast páry (není povoleno)
Krátkodobá provozní oblast
Rozměry
DN 10-50
DN 10-50
| DN | PN | Produktové číslo | A | D | D1 | D2 | D3 | D4 | H | H1 | L | L1 | S | Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10 | 40 | 231010X/MM | 130.0 | 10.0 | 13.5 | 33.7 | Rp 3/8 | 32 | 119 | 86.0 | 153 | 115.0 | 1.6 | 0.5 |
| 15 | 40 | 231015X/MM | 130.0 | 10.0 | 20.0 | 33.7 | Rp 1/2 | 32 | 119 | 86.0 | 158 | 115.0 | 2.0 | 0.6 |
| 20 | 40 | 231020X/MM | 130.0 | 15.0 | 25.0 | 42.4 | Rp 3/4 | 32 | 123 | 87.0 | 165 | 115.0 | 2.0 | 0.7 |
| 25 | 40 | 231025X/MM | 130.0 | 20.0 | 30.0 | 48.3 | Rp 1 | 32 | 125 | 86.0 | 172 | 115.0 | 2.0 | 1.0 |
| 32 | 40 | 231032X/MM | 130.0 | 25.0 | 36.0 | 60.3 | Rp 1 1/4 | 32 | 129 | 85.0 | 195 | 130.0 | 2.0 | 1.4 |
| 40 | 40 | 231040X/MM | 130.0 | 32.0 | 45.0 | 70.0 | Rp 1 1/2 | 32 | 133 | 87.0 | 205 | 130.0 | 2.5 | 1.9 |
| 50 | 40 | 231050X/MM | 130.0 | 40.0 | 54.0 | 76.1 | Rp 2 | 32 | 140 | 88.0 | 240 | 150.0 | 2.6 | 2.9 |
Převodník čísel produktů
| Produktové číslo | EAN | LVI | RSK |
|---|---|---|---|
| 231010X/MM | 6430079560084 | 3765248 | 5496000 |
| 231015X/MM | 6430079560091 | 3765249 | 5495297 |
| 231020X/MM | 6430079560107 | 3765250 | 5495298 |
| 231025X/MM | 6430079560114 | 3765254 | 5495299 |
| 231032X/MM | 6430079560121 | 3765251 | 5495300 |
| 231040X/MM | 6430079560138 | 3765252 | 5495301 |
| 231050X/MM | 6430079560145 | 3765253 | 5495302 |
