Steel ball valve
Series 102, female threads / female threads, reduced bore, DN 10-50, PN 40
DN 10-50
Materials
| Body | DN 10-50: Steel, P235GH (1.0345) |
| Ball | DN 10-50: Stainless steel, X5CrNi18-10 (1.4301) |
| Ball seal | DN 10-50: PTFE+C |
| Stem | DN 10-50: Stainless steel, X8CrNiS18-9 (1.4305) |
| Stem seal | DN 10-50: FPM |
Mounting
| female threads / female threads |
Operation
| DN 10-50 | composite handle |
Operating conditions
| Temperature | -20 °C - +200 °C |
| Leakage rate | A (EN 12266-1) |
Below -20 °C contact manufacturer. Lowest allowed ambient temperature -40 °C.
DN 10-50
water area
Steam area (not allowed)
short-term working area
Dimensions
DN 10-50
DN 10-50
| DN | PN | Product no. | A | D | D1 | D2 | D3 | H | H1 | L | Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 10 | 40 | 102010X | 130.0 | 10.0 | Rp 3/8 | 33.7 | 32 | 119 | 86.0 | 75 | 0.4 |
| 15 | 40 | 102015X | 130.0 | 10.0 | Rp 1/2 | 33.7 | 32 | 119 | 84.0 | 85 | 0.4 |
| 20 | 40 | 102020X | 130.0 | 15.0 | Rp 3/4 | 42.4 | 32 | 123 | 81.0 | 100 | 0.6 |
| 25 | 40 | 102025X | 130.0 | 20.0 | Rp 1 | 48.3 | 32 | 125 | 84.0 | 115 | 0.7 |
| 32 | 40 | 102032X | 130.0 | 25.0 | Rp 1 1/4 | 60.3 | 32 | 129 | 83.0 | 130 | 1.1 |
| 40 | 40 | 102040X | 130.0 | 32.0 | Rp 1 1/2 | 70.0 | 32 | 133 | 84.0 | 150 | 1.4 |
| 50 | 40 | 102050X | 130.0 | 40.0 | Rp 2 | 76.1 | 32 | 140 | 85.0 | 180 | 2.0 |
Product number conversions
| Product no. | EAN | LVI | RSK | NRF |
|---|---|---|---|---|
| 102010X | 6415837556691 | 3755669 | 5495162 | 5599331 |
| 102015X | 6415837556707 | 3755670 | 5495163 | 5599332 |
| 102020X | 6415837556714 | 3755671 | 5495164 | 5599333 |
| 102025X | 6415837556721 | 3755672 | 5495165 | 5599334 |
| 102032X | 6415837556738 | 3755673 | 5495166 | 5599335 |
| 102040X | 6415837556745 | 3755674 | 5495167 | 5599336 |
| 102050X | 6415837556752 | 3755675 | 5495168 | 5599337 |
